Upright SB60 - COVER INSTALLATION

Illustrated Parts Breakdown
Section
SB60 Work Platform6-54
6.2
COVER INSTALLATION
100308-000
ITEM PART DESCRIPTION QTY.
1 100130-000 COVER, TURRET LEFT 1
2 100131-000 COVER, TURRET RIGHT 1
3 100368-000 BEARING, HINGE 4
4 100126-000 GAS SPRING 4
5 100127-000 LATCH, COVER 4
6 100128-000 BUMPER, RUBBER 4
7 100119-000 BALL STUD 13MM - WITH SAFETY CLIP 8
8 100144-000 EXHAUST PIPE WELDMENT 1
9 100350-000 COVER RIB WELDMENT 1
10 100353-000 COVER RIB WELDMENT 1
11 100370-099 DOOR SEAL "C" FT 12
12 100383-099 DOOR SEAL "B" FT 6
13 011273-006 NUT 3/8 JAM 8
14 011253-018 SCREW, HHC 5/16-18 UNC X 2-1/4 4
15 014996-005 WASHER 5/16 SAE FLAT 16
16 011248-005 NUT 5/16-18 ESNA 4
17 011252-006 SCREW HHC 1/4-20 UNC X 3/4 LG 16
18 011248-004 NUT 1/4 ESNA 38
19 014996-004 WASHER 1/4 SAE FLAT 36
20 011252-008 SCREW HHC 1/4-20 UNC X 1 LG 22
21 011238-005 WASHER 5/16 LOCK 8
23 011240-004 WASHER 1/4 FLAT 12
