Upright SB60 - DIFFERENTIAL LOCK (VALVE BLOCK ASSEMBLY)

Illustrated Parts Breakdown
Section
SB60 Work Platform6-60
6.2
DIFFERENTIAL LOCK
(VALVE BLOCK ASSEMBLY)
100317-000
ITEM PART DESCRIPTION QTY.
1 100282-000 DIFF-LOCK VALVE BLOCK 1
3 011934-013 FITTING, 90° ADAPTER 12MB-8MJ 1
4 100444-004 FITTING, TEE 8MFFOR-8MB-8MFFOR 2
5 100434-023 FITTING, 90° ADAPTER 12MFFOR-16MB 1
6 011941-010 FITTING, STR. ADPATER 8MB-8MJ 2
7 100432-015 FITTING, STR. ADAPTER 8MFFOR-8MB 2
8 100432-027 FITTING, STR. ADAPTER 12MFFOR-12MB 2
ITEM PART DESCRIPTION QTY.
10 100435-005 FITTING, 12MFFORS-12FFORS 90° 2
11 100433-001 FITTING, 45° 4MFFOR-4MB 1
12 100432-002 FITTING, STR. 4MFFOR-4MB 6
14 100435-001 FITTING, 4MFFORS-4FFORS 90° 2
15 011941-001 FITTING STR. ADAPTER 4MB-4MJ 4
16 100448-002 FITTING, TEE FF2114T-0808S 1
17 011934-001 FITTING 90° ADAPTER 4MB-4MJ 1
