Illustrated Parts Breakdown
Section
SB60 Work Platform6-68
6.2
LABEL KIT
100024-000 - DIESEL
100024-001 - GAS
ITEM PART DESCRIPTION QTY.
1 061205-002 NAME PLATE/BOOM 1
2 065368-000 TACK 4
5 066552-000 LABEL WARNING EXPLOSIVE GAS 2
6 005221-000 LABEL BATTERY LEVEL 2
7 066555-001 LABEL, CAUTION DO NOT ADJUST 2
8 066556-000
LABEL, CAUTION DESCENDING
PLATFORM
2
9 066553-001 LABEL PINCH POINT 4
10 060197-000 LABEL HYDRAULIC FLUID 1
11 027898-001 LABEL DIESEL FUEL 1
12 064166-000 LABEL, GASOLINE-UNLEADED 1
13 010076-001 LABEL ATTENTION 1
14 010076-000 MANUAL CASE 1
15 100028-000 USER MANUAL 1
16 060565-000 ANSI MANUAL 1
17 011248-004 NUT HEX ESNA 1/4-20 UNC 4
18 011252-008 SCREW HHC X 1/4-20 X 1 4
19 062557-012 MAX LOAD 500 LB/225 KG 1
20 064199-001 LABEL 4WD 1
21 068639-000 LABEL, POWER TO PLATFORM 1
22 064444-000 LABEL USA 1
23 066554-000 LABEL BEFORE OPERATION 3
24 068979-000 LABEL, CHOCK WHEELS 4
25 100340-000 LABEL UPPER CONTROLS-DRIVE 1
26
100340-001 LABEL UPPER CONTROLS-AUX. GAS 1
100340-004 LABEL UPPER CONTROLS-AUX. DSL 1
27 100340-002
LABEL UPPER CONTROLS-EMERGENCY
STOP
1
28 100340-003 LABEL UPPER CONTROLS-AUX. 1
29 100341-000 LABEL, LOWER CONTROLS 1
30 066562-005 LABEL, TIRE PRESSURE 4
32 068632-000 LABEL HOLD DOWN 6
33 100345-000 LABEL READ & UNDERSTAND 1
34 068635-000 LABEL HARNESS POINT 2
35 068637-000 LABEL ARROW YELLOW 2
36 068637-001 LABEL ARROW ORANGE 2
37 066553-004 LABEL PINCH POINT 4
40 062814-000 LABEL INSERT PIN 1
41 100346-000 LABEL WARNING SHEARING 2
42 061683-007 LABEL UPRIGHT 2
43 061683-010 LABEL UPRIGHT 2
44 061683-011 LABEL UPRIGHT (C-WEIGHT) 1
45 100342-000 LABEL SB60 4
46 100343-000 LABEL -BOOM- 2
47 100344-000 LABEL LIFT 2
