Schematics
Section
SB605-2
5.1
REFERENCE NAME FUNCTION LOCATION
DESIGNATION
R4 Relay Trim Up Lower Control Assy
R5 Relay Trim Dn Lower Control Assy
R6 Relay Axle Lock Lower Control Assy
R7 Relay Aux Power Lower Control Assy
R8 Relay Tilt Lower Control Assy
R9 Relay Dump/Mid Throt Lower Control Assy
R10 Relay Brake/High Throt Lower Control Assy
R11 Relay Boom Power Lower Control Assy
R12 Relay Ignition Lower Control Assy
R13 Relay Start Lower Control Assy
R14 Relay Hi Press Extend Lower Control Assy
R15 Relay Power Switch Lower Control Assy
R16 Relay Chassis Cont Power Lower Control Assy
R20 Relay Platform Cont Power Lower Control Assy
R21 Relay Multi-Func Cut-Out Upper Control Assy
R22 Relay Cage Stowed Upper Control Assy
R23 Relay Cage Left Upper Control Assy
R24 Relay Cage Right Upper Control Assy
R25 Relay Jib Down Upper Control Assy
R26 Relay Jib Up Upper Control Assy
R27 Relay Horn Lower Control Assy
S1 Switch Level Upper Control Assy
S2 Switch Jib Upper Control Assy
S3 Switch Platform Rotate Upper Control Assy
S4 Switch Aux Power Upper Control Assy
S6 Switch Torque Upper Control Assy
S7 Switch Emergency Stop Upper Control Assy
S8 Switch Emergency Stop Upper Control Assy
S9 Switch Emergency Stop Upper Control Assy
S10 Switch Foot Interlock Upper Control Assy
S11 Switch Start Lower Control Assy
S12 Switch Aux Power Lower Control Assy
S13 Switch Level Lower Control Assy
S14 Switch Jib Lower Control Assy
S15 Switch Platform Rotate Lower Control Assy
S16 Switch Lift/Lower Lower Control Assy
S17 Switch Swing Lower Control Assy
S18 Switch Extend/Retract Lower Control Assy
S19 Switch Interlock Upper Control Assy
S20 Switch Chassis/Platform Key Lower Control Assy
Switch
S21 Switch Emergency Stop Lower Control Assy
S22 Switch Max Platform Angle Limit Chassis
S23 Switch Proximity Switch Inside Turret next to Boom
pivot
S24 Switch High Drive Interlocks End of Base Boom under
Extend Carrier Track
S26 Switch Oil Pressure Control Module
SOL1 Solenoid Jib Up Chassis
SOL2 Solenoid Jib Down Chassis
SOL3 Solenoid Cage Rotate Right Chassis
SOL4 Solenoid Cage Rotate Left Chassis
SOL5 Solenoid Shift Lower Control Assy
SOL6 Solenoid Steer Right Lower Control Assy
SOL7 Solenoid Steer Left Lower Control Assy
SOL8 Solenoid Trim Up Lower Control Assy
SOL9 Solenoid Trim Down Lower Control Assy
SOL10 Solenoid Axle Lock Lower Control Assy
SOL11 Solenoid Lift Up Lower Control Assy
SOL12 Solenoid Lift Down Lower Control Assy
SOL13 Solenoid Swing Left Lower Control Assy
SOL14 Solenoid Swing Right Lower Control Assy
SOL15 Solenoid Extend Lower Control Assy
SOL16 Solenoid Retract Lower Control Assy
SOL17 Solenoid Dump Lower Control Assy
SOL18 Solenoid Brake Lower Control Assy
SOL19 Solenoid Boom Lower Control Assy
SNSR1 Level Sensor Trip R8 on excess tilt Control Module
SNSR2 Oil Press Sending Provides input to oil Eng Module Assy
Unit pressure meter
SNSR3 Temp Sending Unit Provides input to Eng Module Assy
temperature meter
STR1 Starter Turns engine Eng Module Assy
5.1 Electrical Schematics- Gas 100026-000
Table 5-1: Electrical Schematic Legend, Gasoline Model - 100026-000
REFERENCE NAME FUNCTION LOCATION
DESIGNATION
ALM1 Tilt Alarm Sounds audible warning Upper Control Assy
when level sensor trips R8
ALM2 Horn Warning Alarm Chassis
ALT1 Alternator Charge battery Eng Module Assy
BATT1 Battery, 12V Main Power Eng Module Assy
BATT2 Battery, 12V Aux Power Chassis
BCI1 Battery Charge Isolator Selects battery for charging Engine Module Assy
C1 Controller Drive Upper Control Assy
C2 Controller Boom Extend Upper Control Assy
C3 Controller Turret Rotate Upper Control Assy
C4 Controller Lift/Lwr Upper Control Assy
C5 Controller Superflex Lower Control Assy
C6 Controller Governor Lower Control Assy
CB1 Breaker, 20A Main Power Lower Control Assy
CB2 Breaker, 20A Main Power Lower Control Assy
CB3 Breaker, 20A Main Power Lower Control Assy
COIL1 Coil Provide spark to distributo Eng Module Assy
D3 Diode Ignition Block (Aux) Upper Control Assy
D4 Diode Ignition Block Upper Control Assy
D5 Diode Power to ignition Circuit Lower Control Assy
D6 Diode Interlock Lower Control Assy
D7 Diode Dump Lower Control Assy
D8 Diode Interlock signal to Superflex Upper Control Assy
D9 Diode Spike Protection Upper Control Assy
D10 Diode Spike Protection Upper Control Assy
D11 Diode Spike Protection Upper Control Assy
D12 Diode Spike Protection Upper Control Assy
D13 Diode Boom Power (Jib Up) Upper Control Assy
D14 Diode Boom Power (Jib Down) Upper Control Assy
D15 Diode Boom Power (Cage Right) Upper Control Assy
D16 Diode Boom Power (Cage Left) Upper Control Assy
D17 Diode Spike Protection Lower Control Assy
D18 Diode Spike Protection Lower Control Assy
D19 Diode Spike Protection Lower Control Assy
D20 Diode Spike Protection Lower Control Assy
D21 Diode Spike Protection Lower Control Assy
D22 Diode Spike Protection Lower Control Assy
D23 Diode Superflex Power Lower Control Assy
D24 Diode Dump Control Lower Control Assy
D25 Diode Steer Right Lower Control Assy
D26 Diode Steer Left Lower Control Assy
D27 Diode Spike Protection Lower Control Assy
D28 Diode Spike Protection Lower Control Assy
D29 Diode Spike Protection Lower Control Assy
D30 Diode Spike Protection Lower Control Assy
D31 Diode Spike Protection Lower Control Assy
D32 Diode Spike Protection Lower Control Assy
D33 Diode Spike Protection Lower Control Assy
D34 Diode Spike Protection Lower Control Assy
D35 Diode Power to Boom Power Relay Lower Control Assy
D36 Diode Fuel Pump Engine Module
D37 Diode Power Switch Lower Control Assy
D38 Diode Power Switch Lower Control Assy
D39 Diode To Mid Range Throttle Lower Control Assy
D40 Diode Platform to Boom Power Relay Lower Control Assy
D41 Diode Boom Power Lower Control Assy
D42 Diode Dump Mid/Throt Lower Control Assy
D43 Diode Foot Interlock to Swing Control Upper Control Assy
D44 Diode Hand Interlck to Swing Control Upper Control Assy
D45 Diode Hand Interlock to Superflex Upper Control Assy
DSTR1 Distributor Provides spark to plugs Eng Module Assy
L1 Oil Press Lamp Lights on low pressure Upper Control Assy
L2 Tilt Lamp Lights on excessive angle Upper Control Assy
MTR1 Hour Meter Tracks hours run Lower Control Assy
MTR2 Oil Press Meter Displays oil pressure Lower Control Assy
MTR3 Water Temp Meter Displays water temperature Lower Control Assy
PMP1 Main Pump Supplies oil to hydraulics Eng Module Assy
PMP2 Aux Pump Supplies oil to hydraulics Eng Module Assy
PMP3 Fuel Pump Supplies fuel to engine Eng Module Assy
R1 Relay Shift Lower Control Assy
R2 Relay Steer R Lower Control Assy
R3 Relay Steer L Lower Control Assy
