Schematics
Section
SB605-4
REFERENCE NAME FUNCTION LOCATION
DESIGNATION
R13 Relay Start Lower Control Assy
R14 Relay Hi Press Extend Lower Control Assy
R15 Relay Power Switch Lower Control Assy
R16 Relay Chassis Cont Power Lower Control Assy
R17 Relay Glow Plug Eng Module Assy
R18 Relay Fuel Shutoff Eng Module Assy
R19 Relay Glow Lower Control Assy
R20 Relay Platform Cont Power Lower Control Assy
R21 Relay Multi-Func Cut-Out Upper Control Assy
R22 Relay Cage Stowed Upper Control Assy
R23 Relay Cage Left Upper Control Assy
R24 Relay Cage Right Upper Control Assy
R25 Relay Jib Down Upper Control Assy
R26 Relay Jib Up Upper Control Assy
R27 Relay Horn Lower Control Assy
R28 Throttle Relay Intermediate Speed Engine Module
R29 Throttle Relay High Speed Engine Module
S1 Switch Level Upper Control Assy
S2 Switch Jib Upper Control Assy
S3 Switch Platform Rotate Upper Control Assy
S4 Switch Aux Power Upper Control Assy
S5 Switch Glow Plugs Upper Control Assy
S6 Switch Torque Upper Control Assy
S7 Switch Emergency Stop Upper Control Assy
S8 Switch Emergency Stop Upper Control Assy
S9 Switch Emergency Stop Upper Control Assy
S10 Switch Ignition Upper Control Assy
S11 Switch Horn Upper Control Assy
S12 Switch Max Platform Angle Limit Chassis
S13 Switch Oil Pressure Chassis
S14 Switch Proximity Switch Inside Turret near Boom pivot
S15 Switch Foot Interlock Upper Control Assy
SOL1 Solenoid Jib Up Chassis
SOL2 Solenoid Jib Down Chassis
SOL3 Solenoid Cage Rotate Right Chassis
SOL4 Solenoid Cage Rotate Left Chassis
SOL5 Solenoid Shift Lower Control Assy
SOL6 Solenoid Steer Right Lower Control Assy
SOL7 Solenoid Steer Left Lower Control Assy
SOL8 Solenoid Trim Up Lower Control Assy
SOL9 Solenoid Trim Down Lower Control Assy
SOL10 Solenoid Axle Lock Lower Control Assy
SOL11 Solenoid Lift Up Lower Control Assy
SOL12 Solenoid Lift Down Lower Control Assy
SOL13 Solenoid Swing Left Lower Control Assy
SOL14 Solenoid Swing Right Lower Control Assy
SOL15 Solenoid Extend Lower Control Assy
SOL16 Solenoid Retract Lower Control Assy
SOL17 Solenoid Dump Lower Control Assy
SOL18 Solenoid Brake Lower Control Assy
SOL19 Solenoid Boom Lower Control Assy
SOL20 Solenoid Engages eng starter Eng Module Assy
SOL21 Solenoid Extend high pressure Lower Control Assy
SOL22 Solenoid Fuel Shutoff Eng Module Assy
SNSR1 Level Sensor Trip R8 on excess tilt Lower Control Assy
SNSR2 Oil Press Sending Provides input to oil Eng Module Assy
Unit pressure meter
SNSR3 Temp Sending Unit Provides input to Eng Module Assy
temeprature meter
STR1 Starter Turns engine Eng Module Assy
SW1 Switch Glow Lower Control Assy
SW2 Switch Extend/Retract Lower Control Assy
SW3 Switch Level/Trim Lower Control Assy
SW4 Switch Start Lower Control Assy
SW5 Switch Lift/Lower Lower Control Assy
SW6 Switch Platform Rotate Lower Control Assy
SW7 Switch Keyswitch - Selector Lower Control Assy
SW8 Switch Enable Lower Control Assy
SW9 Switch Jib Lower Control Assy
SW10 Switch Emergency Stop Lower Control Assy
SW11 Switch Aux Power Lower Control Assy
SW12 Switch Swing – Slew Lower Control Assy
SW13 Switch Oil Pressure Eng Module Assy
REFERENCE NAME FUNCTION LOCATION
DESIGNATION
A1 Tilt Alarm Sounds audible warning Upper Control Assy
when level sensor trips R8
A2 Horn Warning Alarm Chassis
ALT1 Alternator Charge battery Eng Module Assy
BATT1 Battery, 12V Main Power Eng Module Assy
BATT2 Battery, 12V Aux Power Chassis
BCI1 Battery Charge Selects battery for charging Engine Module Assy
Isolator
C1 Controller Drive Upper Control Assy
C2 Controller Boom Extend Upper Control Assy
C3 Controller Boom Lift/Turret Rotate Upper Control Assy
C4 Controller Superflex Lower Control Assy
C5 Controller Governor Eng Module Assy
CB1 Breaker, 20A Main Power Lower Control Assy
CB2 Breaker, 20A Main Power Lower Control Assy
CB3 Breaker, 20A Main Power Lower Control Assy
D1 Diode Ignition Block (Aux) Upper Control Assy
D2 Diode Ignition Block Upper Control Assy
D3 Diode Swing Control Upper Control Assy
D4 Diode Manual Controls Upper Control Assy
D5 Diode Manual Controls Upper Control Assy
D6 Diode Spike Protection Upper Control Assy
D7 Diode Spike Protection Upper Control Assy
D8 Diode Spike Protection Upper Control Assy
D9 Diode Spike Protection Upper Control Assy
D10 Diode Boom Power (Jib Up) Upper Control Assy
D11 Diode Boom Power (Jib Down) Upper Control Assy
D12 Diode Boom Power (Cage Right) Upper Control Assy
D13 Diode Boom Power (Cage Left) Upper Control Assy
D14 Diode Swing Control Upper Control Assy
D15 Diode Ignition Block Upper Control Assy
D16 Diode Ignition Block Lower Control Assy
D17 Diode Lower Control Interlock Lower Control Assy
D18 Diode Spike Protection Lower Control Assy
D19 Diode Spike Protection Lower Control Assy
D20 Diode Spike Protection Lower Control Assy
D21 Diode Spike Protection Lower Control Assy
D22 Diode Spike Protection Lower Control Assy
D23 Diode Spike Protection Lower Control Assy
D24 Diode Steer Left Lower Control Assy
D25 Diode Steer Right Lower Control Assy
D26 Diode Dump Control Lower Control Assy
D27 Diode Governor Control Isolation Lower Control Assy
D28 Diode Governor Control Isolation Lower Control Assy
D29 Diode Superflex Power Lower Control Assy
D30 Diode Aux Power Isolation (Dump) Lower Control Assy
D31 Diode Aux Power Isolation (Boom) Lower Control Assy
D32 Diode Aux Power Isolation (Boom) Lower Control Assy
D33 Diode Main/Aux Power Isolation Lower Control Assy
D34 Diode Main/Aux Power Isolation Lower Control Assy
D35 Diode Glow Block Lower Control Assy
D36 Diode Main/Aux Power Isolation Lower Control Assy
D37 Diode Alternator Isolation Eng Module Assy
L1 Oil Press Lamp Lights on low pressure Upper Control Assy
L2 Tilt Lamp Lights on excessive angle Upper Control Assy
MTR1 Hour Meter Records hours run Lower Control Assy
MTR2 Oil Press Meter Displays oil pressure Lower Control Assy
MTR3 Water Temp Meter Displays water temperature Lower Control Assy
PMP1 Main Pump Supplies oil to hydraulics Eng Module Assy
PMP2 Aux Pump Supplies oil to hydraulics Eng Module Assy
R1 Relay Shift Lower Control Assy
R2 Relay Steer R Lower Control Assy
R3 Relay Steer L Lower Control Assy
R4 Relay Trim Up Lower Control Assy
R5 Relay Trim Dn Lower Control Assy
R6 Relay Axle Lock Lower Control Assy
R7 Relay Aux Power Lower Control Assy
R8 Relay Tilt Lower Control Assy
R9 Relay Dump/Mid Throt Lower Control Assy
R10 Relay Brake/High Throt Lower Control Assy
R11 Relay Boom Power Lower Control Assy
R12 Relay Ignition Lower Control Assy
5.1 Electrical Schematics - Diesel 100026-004
5.1
Table 5-2: Electrical Schematic Legend, Diesel Model - 100026-004
