Upright SB60 - Page 65

Schematics
Section
SB60 5-15
5.4
Front & Rear Drive
Check Valves
(Valve Block Assembly)
100716-000 & 100717-000
ITEM PART DESCRIPTION QTY.
1 100713-000 VALVE BLOCK, ANTI-CAV CHECK 1
2 100432-015 FITTING 8MB-8MFFOR STRAIGHT 3
3 011934-007 FITTING 8MB-6MJ 90° ELBOW 1
4 100714-000 VALVE BLOCK, 2 STATION CHECK 1
5 100432-027 FITTING 12MB-12MFFOR STRAIGHT 2
6 100432-016 FITTING 10MB-8MFFOR STRAIGHT 4
7 020021-008 FITTING 8MB PLUG 1
8 011934-007 FITTING 8MB-6MJ 90° ELBOW 1
