Schematics
Section
SB60 5-23
Lower Controller Assembly,
Gas
100019-000
ITEM PART DESCRIPTION QTY.
1 100307-000 ENCLOSURE 1
3 68582-020 CIRCUIT BREAKER, 20 AMP 3
4 12798-000 TOGGLE SWITCH, SPDT 7
5 12798-005 TOGGLE SWITCH, DPDT 1
6 100335-000 SELECTOR SWITCH, KEY OPERATED 1
7 64417-001 LATCH PLATE 1
8 64443-001 CONTACT BLOCK, NC 2
9 64446-003 OPERATOR, RED "MUSHROOM" BUTTON 1
10 100331-000 OIL PRESSURE GAUGE 1
11 100330-000 TEMPERATURE GAUGE 1
12 15752-000 HOUR METER 1
13 67662-001 BASE, RELAY SINGLE POLE 1 7
14 67661-001 RELAY, SINGLE POLE 17
15 67662-005 RETAINER CLIP, RELAY 1 7
16 67893-005 DIN RAIL 10-1/2" LENGTH 2
17 100316-000 MOUNTING PLATE 1
18 68698-001 TERMINAL BLOCK, TAN 43
19 68698-000 TERMINAL BLOCK, ORANGE 2
20 68698-002 TERMINAL BLOCK, BLUE 6
21 29925-001 CORD GRIP 3
22 100336-000 CONTROLLER "SUPER-FLEX" KIT 1
23 100299-000 SPACER 3
24 68698-004 END SECTION 2
25 67660-006 END BLOCK, LOCKING 6
26 26551-005 POP RIVET 1/8" DIA (3/16-1/4 GRIP) 6
27 66516-008 PLUG, 1/2" DIA 1
28 012798-006 TOGGLE SWITCH 1
29 29939-003 LOCKNUT 3/4" NPT 3
31 11708-004 SCR, RD HD #8-32 UNC X 1/2 6
32 11240-003 WASHER, FLAT #10 6
33 68860-000 CONTACT BLOCK, NO DOUBLE 2
34 068773-002 JUMPER, 2 PIN 1
35 100315-000 MOUNTING BRACKET 1
36 11252-006 SCREW, HHC 1/4-20 X 3/4 4
37 11248-004 LOCKNUT, 1/4-20 UNC ESNA 4
38 67893-006 DIN RAIL 8-1/2" LENGTH 1
39 100298-000 NUMBER STRIP #1 - #50 1
40 100336-015 WIRE HARNESS 2
41 100316-016 WIRE HARNESS 1
42 068773-003 JUMPER, 3 PIN 1
43 060214-099 CABLE 16 GA 15 COND FT 11
44 100338-001 CONNECTOR, FEMALE 21 PIN 1
45 100338-011 CONNECTOR, 12 GA PIN 3
46 100338-013 CONNECTOR, 16 GA PIN 15
47 100338-005 BOOT 1
48 68764-000 PLUG SEALING 3
SEE NEXT PAGE
