Schematics
Section
SB60 5-33
Upper Controller Assembly
Gas, SB60
100017-000
ITEM PART DESCRIPTION QTY.
1 100325-000 DRIVE CONTROLLER REF
2 100326-000 LIFT CONTROLLER REF
3 100327-000 EXTEND CONTROLLER REF
4 100309-000 UPPER CONTROL BOX 1
5 100310-000 STIFFENER, UPPER CONTROLLER 1
6 012797-000 SWITCH TOGGLE SPST MAINTAINED 1
7 012798-000 SWITCH TOGGLE SPDT MOMENTARY 3
8 068590-000 BASE INDICATOR SPDT MOMENTARY 2
9 068591-001 LAMP T-2 1/2 2
10 068595-002 LENS AMBER 1
11 068595-001 LENS RED 1
12 064446-003 EMERGENCY STOP BUTTON 1
13 064443-002 CONTACT BLOCK NC 3
14 064417-001 FLANGE MOUNT 2
15 012798-005 SWITCH TOGGLE DPST MOMENTARY 1
16 029871-001 SWITCH TOGGLE SPDT MAINTAINED 1
17 067654-000 PUSH BUTTON, FLUSH (BLACK) 1
18 064443-001 CONTACT BLOCK NO 1
SEE NEXT PAGE
