Upright SB60 - Page 88

Schematics
Section
SB605-38
Engine Module Assembly
Diesel
100012-000
ITEM PART DESCRIPTION QTY.
201 100338-000 CONNECTOR, MALE (21 PIN) 1
202 100338-005 BOOT 1
205 100338-012 CONTACT, 12 GA SOCKET 3
207 100338-014 CONTACT, 16 GA SOCKET 15
209 068764-000 PLUG, SEALING 3
210 029480-099 WIRE, 10 GA RED FT 6
211 029484-099 WIRE, 8 GA RED FT 6
212 029452-099 WIRE, 16 GA BLACK FT 6
213 029451-099 WIRE, 16 GA WHITE FT 6
214 029454-099 WIRE, 16 GA RED FT 6
215 029457-099 WIRE, 16 GA GREEN FT 6
216 029453-099 WIRE, 16 GA ORANGE FT 6
217 029450-099 WIRE, 16 GA BLUE FT 6
218 029479-099 WIRE, 16 GA WHITE/BLACK FT 6
219 029478-099 WIRE, 16 GA RED/BLACK FT 6
220 005491-099 WIRE, 16 GA GREEN/BLACK FT 6
221 029477-099 WIRE, 16 GA ORANGE/BLACK FT 6
222 029475-099 WIRE, 16 GA BLUE/BLACK FT 6
223 029351-099 WIRE, 16 GA BLACK/WHITE FT 6
224 029352-099 WIRE, 16 GA RED/WHITE FT 6
225 029353-099 WIRE, 16 GA GREEN/WHITE FT 6
226 029354-099 WIRE, 16 GA BLUE/WHITE FT 6
227 029470-099 WIRE, 12 GA RED FT 6
228 064195-080 BATTERY CABLE ASSY X 80 LG 1
229 064195-050 BATTERY CABLE ASSY X 50 LG 1
230 029931-003 CONN FEM PUSH (.25) 16-14 GA 7
231 029617-002 CONN MALE PUSH (.25) 16-14 GA 6
232 029601-039 CONN RING TERM 0-5/16 12-10 GA 8
233 029601-012 CONN RING TERM. #8 0 16-14 GA 2
234 029620-003 CONNECTOR, BUTT 10-12 GA 3
235 029610-006 CONN FORK TERM #8 0 14-16 GA 4
236 029825-002 DIODE, 5 AMP 1
237 014435-001 BATTERY TERMINAL 2
238 029601-025 CONN RING TERM 0 5/16 8 GA 4
239 064195-032 BATTERY CABLE ASSY X 32 LG 1
240 029419-099 WIRE, 12 GA RED. GRN 6
241 029418-099 WIRE, 12 GA RED/BLK 12
5.10
