Introduction
Operation Manual Page 3
I NTRODUCTION
This manual covers operation of the SL26/30 Speed Level Series Self-Propelled Work Platforms. This
manual must be stored on the machine at all times.
G ENERAL D ESCRIPTION
Figure 1: SL26/30 SL Series
1. Platform
WARNING
!
!
DO NOT use the maintenance platform
without guardrails properly assembled
and in place
2. Elevating Assembly
3. Chassis
4. Power Module
5. Control Module
6. Platform Controls
7. Manual Case
8. Chassis Controls
9. Hydraulic Fluid Reservoir
1
2
3
4
5
6
7
8
9

Upright SL26SL Specifications

General

Brand	Upright
Model	SL26SL
Category	Scissor Lifts
Language	English
