Upright SL26SL Service Manual

6-4
Illustrated Parts Breakdown - Chassis Assembly
SL30SL Service & Parts
Chassis Assembly
505501-000
ITEM
PART
NUMBER
DESCRIPTION QTY
1
064320-001 WELDMENT, 1ST POST 1
2
064331-001 WELDMENT, LEVEL PIVOT 1
3
064300-002 WELDMENT, CHASSIS 1
4
064324-002 WELDMENT, FRONT AXLE 1
5
064343-001 TRUNION 2
6
011256-014 SCREW, TRUNION 8
7
011238-008 WASHER 8
8
064383-000 THRUST BEARING, LEVEL PIVOT 4
9
062642-030 BUSHING, LEVEL PIVOT 4
10
064811-000 HUB, REAR 2
11
011754-012 SPLIT PIN 4
12
014122-001 WHEEL BOLT 20
13
069129-000 WHEEL, RIGHT HAND 2
14
069129-001 WHEEL, LEFT HAND 2
15
505201-000 DRIVE MOTOR, REAR 2
16
011257-014 BOLT, DRIVE MOTOR, REAR 8
17
063905-101 CYLINDER, STEER 1
18
067606-013 BUSHING, AXLE / MOTOR MOUNT 2
19
505565-000 STEER LINK ARM 2
20
505564-000 MOTOR MOUNT 2
21
505202-000 DRIVE MOTOR, FRONT 2
22
064812-000 HUB, FRONT 2
23
-- -
24
011754-012 SPLIT PIN 4
25
-- -
26
064034-001 PIN, MOTOR MOUNT 4
27
062642-001 BUSHING, MOTOR MOUNT 4
28
063927-001 ROSE BEARING, STEERING CYL 2
29
062642-030 BUSHING, AXLE TO CHASSIS
30
064336-000 PIVOT PIN, FRONT AXLE 1
31
508020-000 PIVOT PIN, FLOAT CYL - AXLE 2
32
064642-100 CYLINDER, CHASSIS - AXLE
33
064296-002 LIMIT SWITCH, FLOAT, BODY 1
34
064367-001 BRACKET, LIMIT SWITCH MOUNT 1
35
064339-001 PIN, 1ST POST / LEVEL PIVOT / CHASSIS 1
36
508021-000 PIN, LEVEL CYLINDER - 1ST POST 4
37
064345-100 CYLINDER, FLOAT 1
38
064349-000 SPACER 1
39
- M16 BOLT, ROSE BEARING 1
40
- M16 BOLT, STEARING LINKAGE 1
41
011256-040 BOLT, FRONT MOTOR MOUNT 4
42
011239-008 WASHER, FRONT MOTOR 4
43
011240-000 WASHER, REAR MOTOR 4
44
011248-008 NUT, REAR MOTOR 4
ITEM
PART
NUMBER
DESCRIPTION QTY
