urmet domus 788/21 - Switchboard and Door Phone Power Unit Replacements (9006;3, 9008;14); Door Unit Replacements (5150;500 with 1128;500)

BASIC SYSTEM DIAGRAMS
INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITY
14
−−−−
sec.1f
DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams
REPLACING SWITCHBOARD SYSTEM POWER UNIT Ref. 9006/3 WITH Ref. 786/3A
REPLACING DOOR PHONE POWER UNIT Ref. 9008/14 WITH Ref. 786/38A
REPLACING DOOR UNIT Ref. 5150/500 WITH Ref. 1128/500
REPLACING SWITCHBOARD SYSTEM POWER UNIT Ref. 9006/3 WITH Ref. 786/3A
The Ref. 786/3A power unit can replace the obsolete 9006/3 model.
The terminals correspond as follows:
REPLACING DOOR PHONE POWER UNIT Ref. 9008/14 WITH Ref. 786/38A
The Ref. 786/38A power unit can replace the obsolete 9008/14 model.
The terminals correspond as follows:
REPLACING DOOR UNIT Ref. 5150/500 WITH Ref. 1128/500
Ref. 9006/3 Ref. 786/3
~110
~220
~240
~0
~12
-15
+15
~0
Not available
~230
Not available
~0
~12
-15
+15
0
OUTPUTS
POWER
Ref. 9008/14 Ref. 786/38A
~110
~220
~240
~0
~12
~18
+6
-6
-J
~0
~110
~230
Not available
~0
~12
~18
-J
-6
+6
0
OUTPUTS
POWER
Ref. 5150/500 Ref. 1128/500
-
1
1A
2
+
-
1
1A
2
+
