urmet domus 788/21 - Relay Box Replacements (9332;8, 788;8 with 788;58); 12 VAC Transformer Replacements (9000;20 with 9000;230)

BASIC SYSTEM DIAGRAMS
INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITY
18
−−−−
sec.1f
DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams
REPLACING RELAY BOX Ref. 9332/8 AND Ref. 788/8 WITH Ref. 788/58
REPLACING 12VAC TRANSFORMER Ref. 9000/20 WITH Ref. 9000/230
REPLACING RELAY BOX Ref. 9332/8 AND Ref. 788/8 WITH Ref. 788/58
The Ref. 788/58 relay box can replace the obsolete 9332/8 and 788/8 model.
The terminals correspond as follows:
Note : Terminals C1, C2, ~12 of relay Ref. 788/58 must be connected together by jumpers and connected to ~12.
REPLACING 12VAC TRANSFORMER Ref. 9000/20 WITH Ref. 9000/230
The 9000/230 transformer can replace the obsolete 9000/20 model.
The terminals correspond as follows:
(∗) Not available in Italy.
