urmet domus IPerCom - 1060;13 Mounting Height

BS8300 6.6 for access control systems refers to the
between 900mm and 1050mm
The “Activation Pad” i.e. the proximity reader is centred at a height of 1050mm.
Wheelchair Housing Design Guide (WHDG) refers to a height of 1200mm to the
highest function.
Following the recommended mount
located at 1150mm.
This places the top of the panel at 1340mm
1060/13 mounting height
1340
mm
BS8300 6.6 for access control systems refers to the
between 900mm and 1050mm
The “Activation Pad” i.e. the proximity reader is centred at a height of 1050mm.
Wheelchair Housing Design Guide (WHDG) refers to a height of 1200mm to the
highest function.
Following the recommended mount
located at 1150mm.
This places the top of the panel at 1340mm
1060/13 mounting height
mm
