USAutomatic PATRIOT II

Other manuals for USAutomatic PATRIOT II

Installation And Owner's Manual44 pages

Questions and Answers

M
Michael HuffmanNov 25, 2025
How to troubleshoot a USAutomatic Patriot I Gate Opener that won't operate?
- B
  Brian HowardNov 25, 2025
  To troubleshoot a USAutomatic Patriot I Gate Opener that won't operate: remove the control box cover and press the “Open/Close Command” push button. If that doesn't work, press the “Reset” push button and then push the “Open/Close Command” button. Check and replace the 15-amp fuse if it's blown. Verify the dipswitch settings are correct for the actuator connection (Master or Slave). Charge or replace the battery, testing with jumper cables from a 12vdc vehicle battery. Adjust the limit switch if both limit LEDs are on in the closed position. Locate and repair or replace any activated accessory if its LED is on. Disconnect the green J2 connector and press the “Open/Close Command” button; if it operates, check step 4b. Ensure DS1 switch 8 is off. If needed, switch the actuator connectors (X1...
K
Karen FlowersAug 25, 2025
How to fix USAutomatic PATRIOT II remote not working?
- D
  Dr. Jennifer RiceAug 25, 2025
  If your USAutomatic Gate Opener remote isn't working, ensure the green J2 connector on the control board is securely connected. Replace the battery in the transmitter. Also, check that the dipswitches in the transmitter are set identically to those in the receiver. If the “Push Button Input” LED comes on but the gate doesn't operate, verify the 15-amp fuse on the Patriot control board is not blown. Finally, check if a safety accessory connected to the green J2 connector is active and correct the problem.
D
dawncarterAug 25, 2025
What to do if my USAutomatic Gate Opener won't close automatically?
- A
  Alicia GreerAug 26, 2025
  If your USAutomatic Gate Opener isn't closing automatically, check that DS1 switch 1 is turned on. Ensure that only one of DS1 switches 3 or 4 is on, turning off the one not in use. Adjust the limit switches if needed. Also, try disconnecting the green J2 connector from the control board and pressing the “Open/Close Command” push button to close the gate. Verify that any accessory connected to the J2 connector that is activated (LED is on) is working correctly.
W
williamsdanielAug 27, 2025
Why does the USAutomatic PATRIOT II Gate Opener fuse blow when opening or closing?
- S
  Sean ParkerAug 27, 2025
  If the 15 amp fuse on your USAutomatic Gate Opener control board blows when giving an Open/Close command, it could be due to something preventing the gate from moving, incorrect limit switch settings, or a wiring problem. Open the control box to access the Patriot control board. Adjust the limit switches if the open limit LED is on when the gate is closed, or if the close limit LED is on when the gate is open. Check all splices and ensure the actuator connector is properly connected at the control board. If problems persist, contact the factory for troubleshooting.
M
Mary FreemanAug 28, 2025
What to do if my USAutomatic Patriot II dual gate won't operate?
- D
  dmooreAug 28, 2025
  If your USAutomatic Patriot II dual gate won't operate, follow steps 1 through 6 from the single gate troubleshooting. Disconnect both actuator connectors (X1 and X2), then turn off switch 4 and turn on switch 3 on the DS1 dipswitches. Press the “Open/Close Command” button to verify gate operation. Disconnect the actuator plug and connect the other actuator plug into the X1 connector, then press the “Open/Close Command” button to verify proper operation. Revert DS1 switch 3 off and switch 4 on, then repeat steps 2 and 3 using the X2 connector. Check wiring splices for moisture and ensure correct wiring of the slave actuator.
B
bryanburnsSep 16, 2025
Why are the lights on my USAutomatic PATRIOT II Gate Opener charger but it's not charging?
- H
  hmorganSep 16, 2025
  If the USAutomatic Gate Opener charger or charge controller shows that the 'External Power or Solar Power Light & Detection Light are ON', the battery is likely not connected to the charger or charge controller. Verify that the 2-wire harness going to the battery is connected to both the battery and the charger or charge controller.
S
Sharon BentleySep 8, 2025
What to do if USAutomatic PATRIOT II Gate Opener stops and reverses during opening/closing?
- J
  jgibbsSep 8, 2025
  If your USAutomatic gate begins to open or close but stops and reverses after a couple of seconds, remove the control box cover and find the sensitivity adjustment potentiometer on the Patriot control board. Adjust the white center in a clockwise direction to increase the force. A setting of 5 usually works for most gates. If your gate needs a setting above 8, it likely has a problem that needs fixing, such as incorrect hinges, the gate touching the ground, the gate not being level, or a bent actuator arm connected to the gate. Identify and correct the underlying issue.
J
Jack JohnsonSep 12, 2025
Why does my USAutomatic dual gate open/close immediately after operation?
- D
  daniel23Sep 12, 2025
  If your dual USAutomatic gate opens correctly then closes immediately, or closes correctly then opens immediately, determine which gate needs adjustment. Locate the DS1 switches on the Patriot control board. Turn off switch 4 to disable one gate. Operate the gate and verify that it stops in the correct position. If so, turn switch 4 back on and turn switch 3 off. Operate the other gate and verify that it stops correctly. If one or both gates don't stop correctly, identify the gate needing adjustment and refer to problem 6, steps 1 through 5 for instructions.
G
gonzalesrussellSep 3, 2025
Why USAutomatic gate opens but won't close using transmitter?
- M
  Melissa JenkinsSep 3, 2025
  If your USAutomatic gate opens using the transmitter but won't close (Low Current Receiver only), the P2 relay may be programmed to latch mode. Refer to page 21 to reset the receiver P2 relay to momentary mode. Also, return to troubleshooting section 4 and perform steps 1-6.
W
William ThompsonSep 1, 2025
How to fix Oracle Remote/Transmitter not operating USAutomatic gate?
- E
  Eric MilesSep 1, 2025
  If your Oracle Remote/Transmitter will not operate the gate, verify the wiring from the DFGCU receiver to J5 is not damaged. Replace the batteries in the remote/transmitter if necessary. If problems persist, call the factory for help.

Summary

Introduction and Safety First

Product Overview and Battery Requirements

Introduces the Patriot gate operator series and specifies battery type.

Installation Safety Guidelines

Details crucial safety precautions for gate operator installation.

Gate Design and Preparation Essentials

Covers gate qualifications, design, and tool requirements.

Parts, Hardware, and Accessories

Component and Hardware Inventory

Lists all parts and hardware included with operators.

System Accessories Guide

Describes optional accessories like keypads, locks, and sensors.

Step-by-Step Installation Guide

Site Review and Opening Method Determination

Planning the installation location and gate swing direction.

Actuator Mounting and Tube Installation

Covers various mounting methods for actuator brackets and tubes.

Control Box, Board, and Accessory Installation

Installing the main control components and accessories.

Wiring, Battery, and Charger Setup

Connecting power sources and the battery.

Control Board Configuration and Settings

Setting dipswitches, limits, and features.

Final Installation Checks and Safety Signs

Performing final steps like safety signs and manual release.

Operation, Maintenance, and Troubleshooting

Entrapment Zones and Periodic Maintenance

Identifying safety zones and service schedule.

Troubleshooting Common Issues

Overview of problems and solutions.

Detailed Symptom-Based Troubleshooting

Step-by-step solutions for specific gate problems.

Appendix and Warranty

Appendix: Solar Systems and Accessories

Information on solar performance and extensions.

Limited Warranty Information

Details on product warranty coverage and claims.

USAutomatic PATRIOT II Specifications

General

Power Supply	120VAC or 240VAC
Motor Type	DC motor
Gate Weight Capacity	up to 1000 lbs
Gate Length Capacity	up to 20 feet
Remote Control	Yes
Warranty	5 year residential / 3 year commercial
Safety Features	Obstruction Detection
Remote Control Type	433 MHz
