USCutter MH200 - Page 5

5
1.2 - 
Control Panel:
Easy to use buttons
& LCD screen.
Pinch Rollers:
Hold media in place
Double Rulers:
Ensure accurate
cutting.
Roller Bars:
Hold vinyl
material
Blade Holder:
Catch Basket:
Prevents dirt and dust
from making contact
with vinyl. (When
purchased with a stand)
Carriage Head:
Moves the blade
across cutting area.
Stand:
Available on
MH200 28" & above.
(When purchased
with a stand)
Power Switch: USB Port:
Connect your MH200
to your computer
Pinch Roller Lever:
Move pinch rollers
up & down.
Blade Holder
Storage Slots
(On Stand Crossbar):
Drop in extra
bladeholder and

access
Trimming Groove:
Guide for trimming
tool to cut vinyl into
sheets.
