14
OIL ALERT SYSTEM
GROUND TERMINAL
GROUND TERMINAL
OIL ALERT INDICATOR
LIGHT (RED)
The generator ground terminal is connected to the frame of the
generator, the metal non-current-carrying parts of the generator, and
the ground terminals of each receptacle.
Before using the ground terminal, consult a qualified electrician,
electrical inspector or local agency having jurisdiction for local codes
or ordinances that apply to the intended use of the generator.
If the engine stops or the Oil Alert indicator light comes on when you
pull the starter grip, check the engine oil level (see page ) before
troubleshooting in other areas.
The Oil Alert
system is designed to prevent engine damage caused
by an insufficient amount of oil in the crankcase. Before the oil level in
the crankcase can fall below a safe limit, the Oil Alert indicator light
comes on and the Oil Alert system automatically will stop the engine
(the engine switch will remain in the ON position).
28
