Section 10 MAINTENANCE AND OPERATION INFORMATION
10-5
15
Gently pull the cleaning shaft as far as it will go, push and
pull it several times, and then push it back in.
IMPORTANT!
Do not pull the cleaning shaft with force or pull it out completely.
16
Remove the cleaning brush.
17
Pull up the left cover 1 handle to open the left cover 1.
11
Attach the grid cleaner to the machine body aligning with the
notches.
12
Gently pull the electrostatic section as far as it will go, push
and pull it several times, and then push it back in.
13
Remove the grid cleaner and replace the cap.
14
Fit the new waste toner box into the copier.
1
2
To Next Page
