2HL/2HM/2HN
1-5-24
12. Remove the two screws and then remove
the MP paper feed lower unit.
Figure 1-5-29
13. Remove the three connectors.
Figure 1-5-30
Screw
Screw
MP paper feed
lower unit
Connector
Connector
Connector
