2HL/2HM/2HN-1
2-4-4
(3) Maintenance parts list
220-240 V AC model
Maintenance part name
Part No.
Alternative
part No.
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Maintenance kit MK-550 MK-550/MAINTENANCE KIT 1702HM3EU0 072HM3EU 15 -
Drum unit DK-550 302HM93010 2HM93010 - -
Paper feed roller assembly HOLDER FEED ASSY SP 302HN94201 2HN94201 - -
Developing unit Y DV-560(Y) 302HN93020 2HN93020 - -
Developing unit K DV-560(K) 302HN93010 2HN93010 - -
Developing unit C DV-560(C) 302HN93030 2HN93030 - -
Developing unit M DV-560(M) 302HN93040 2HN93040 - -
Fuser unit FK-560(E) 302HN93070 2HN93070 - -
Intermediate transfer unit TR-560 302HN93060 2HN93060 - -
MP paper feed roller
ROLLER M/P ASSY /43487B0027 A4
5AAVR0LL+051 2CL16130 - -
Retard roller RETARD ROLLER ASSY 302F909170 2F909170 - -
Maintenance kit MK-560 MK-560/MAINTENANCE KIT 1702HN3EU0 072HN3EU 15 -
Paper feed roller assembly HOLDER FEED ASSY SP 302HN94201 2HN94201 - -
Developing unit Y DV-560(Y) 302HN93020 2HN93020 - -
Developing unit K DV-560(K) 302HN93010 2HN93010 - -
Developing unit C DV-560(C) 302HN93030 2HN93030 - -
Developing unit M DV-560(M) 302HN93040 2HN93040 - -
Drum unit DK-560 302HN93050 2HN93050 - -
Fuser unit FK-560(E) 302HN93070 2HN93070 - -
Intermediate transfer unit TR-560 302HN93060 2HN93060 - -
MP paper feed roller
ROLLER M/P ASSY /43487B0027 A4
5AAVR0LL+051 2CL16130 - -
Retard roller RETARD ROLLER ASSY 302F909170 2F909170 - -
