Technical Bulletin UTAX
UTAX
CLP 3721
CLP 3726
T
A
TA
CLP 4721
CLP 4726
TB 08 / Correcting Parts List - Dev. Release Motor etc.
Pers-Hor/M
Date: 26-10-2011
T OPIC :
The part numbers of the developing release section are registered.
No.
Old Part
No.
New Part
No.
Description
Q’ty Compatibility
Remarks
Old New Old New
1 ---------- 2KV31190 SPRING CLUTCH B - 1
- O
*
2 ---------- 2KV31170 ARM CLUTCH C - 1
- O
*
3 ---------- 2KV31130 GEAR Z36L - 1
- O
*
4 ---------- 2HN31530 GEAR WORM - 1
- O
*
5 ---------- 2KV00070 MOTOR- DC ASSY DLP - 1
- O
*
* Set up to service parts this time
Classification:
Entire Stock Rework
In-Field modification at next visit
In-Field modification by case
X
No modification necessary
Field Measure:
Service information only


Serial No.:
2
3
4
1
5
