Utax P-4030DN User Manual

2-7
Preparation before Use
Installing Software
Ensure the printer is plugged in and connected to the PC before installing the printer driver and utilities from the Product
Library disc.
Software
The following software can be installed from the provided Product Library disc.
In Express Mode, the Printing System Driver and Fonts are installed automatically. In Custom Mode, select and install the
software.
: Installed as standard. : Installed if selected.
Installing the Software in Windows
If you are connecting this printer to a Windows PC, follow the next steps to install the printer driver. The example shows you
how to connect your printer to a Windows 7.
You can use either Express Mode or Custom Mode to install the software. Express Mode automatically detects connected
printers and installs the required software. Use Custom Mode if you want to specify the printer port and select the software
to be installed.
1 Turn on the computer and start up Windows.
If the Welcome to the Found New Hardware Wizard dialog box
displays, select Cancel.
2 Insert the Product Library disc supplied with the printer into the optical
drive of the PC. In Windows 7, Windows Server 2008/R2 and
Software Function Description
Installation Method
Express
Mode
Custom
Mode
Printing System Driver Print Driver for printing files on a computer with the
machine. This printer driver enables full use of the
machine’s features.
Printing System (XPS)
Driver
Printer driver for the XPS (XML Paper
Specification) format developed by Microsoft
Corporation. (Windows 7, Windows Vista,
Windows Server 2008/R2 only.)
—
PCL mini-driver A Microsoft Mini Driver type driver which emulates
and outputs both PCL and KPDL. KPDL is
Kyocera’s implementation of the PostScript
language. With this driver, it is only possible to
use a limited number of all the functions of the
machine and the optional functions there are.
—
KPDL mini-driver —
NETWORK PRINT
MONITOR
Utility Utility that enables the machine, when connected
to a network, to be monitored.
—
Network Tool for Direct
Printing
Simple printing of PDF documents. —
Fonts These are the screen fonts equivalent to the
printer fonts.
Note In Windows operating systems, you must be logged on with administrator rights to install the printer driver.

Utax P-4030DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	32 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, IBM ProPrinter XL24E, PCL 5e, PCL 6, PCL XL, PDF 1.5, PostScript 3
Total input capacity	500 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Thicker paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Internal memory	256 MB
Processor model	465
Processor family	PowerPC
Compatible memory cards	SD
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Certification	GS/TÜV, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	3 W
Power consumption (standby)	13.3 W
Power consumption (printing)	618 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	320 mm
Weight	14600 g
