Utax P-5030DN Service Manual

2LV/2L1/2L2/2MS/2MT-6
No.
Content
Check procedure & check point
Remark 1
P-4030D, P-4030DN, P-4530DN,
P-5030DN, P-6030DN
F33X
An error is detected at the
Scan management section
1) Check connection of the harness (Scan/DP board - main board) and connectors and
check function.
2) Format the HDD and check function. (U024 FULL formatting) (*1)
3) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
4) Replace the Scan/DP board and check function.
5) Replace the main board and check function.
6) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
-
F34X
An error is detected at the
Panel management section
1) Check connection of the harness (Panel board - main board) and connectors and
check function.
2) Format the HDD and check function. (U024 FULL formatting) (*1)
3) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
4) Replace the panel board and check function. (*2)
5) Replace the main board and check function.
6) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
(*2) For the models separating the panel/main PWBs.
Check procedure is partly corrected as below.
2) Format the SSD and check function.([Formatting SSD)
3) (Not applicable)
[Main - Panel Interface] (Engine board relays)
Main board: YC2
Engine board: YC20, YC17
Panel board: YC1
F35X
An error is detected at the
Print control section
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
Check procedure is partly corrected as below.
1) Format the SSD and check function.([Formatting SSD)
2) (Not applicable)
4) Replace the SSD and check function.
F36X
An error is detected at the
Print management section
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
Check procedure is partly corrected as below.
1) Format the SSD and check function.([Formatting SSD)
2) (Not applicable)
4) Replace the SSD and check function.
F37X
An error is detected at the FAX
management section
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
3) Execute the U671 Clear FAX back up data (FAX DIMM clear) and check function.
(*3)
(Take cae of the received data since it is cleared)
4) Replace the FAX_DIMM and check function.
5) Replace the main board and check function.
6) Replace the HDD and check function. (*1)
7) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
(*3) For the models using the main PWB with the flash for the FAX data.
-
2-4-17

Utax P-5030DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Duplex print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.5, PostScript 3
Total input capacity	500 sheets
Paper tray media types	Glossy paper, Matte paper, Plain paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Internal memory	256 MB
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	12.8 W
Power consumption (printing)	677 W
Power consumption (PowerSave)	1.6 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	320 mm
Weight	14600 g
