Chapter 2: Product description
Stratos EX Hazardous Area Aspirating Smoke Detection System Installation Manual 13
Outside the detector
Figure 2 below shows external components on an EX detector.
WARNING: Removal of the detector screw down protective cover in most
applications where this product is installed will require a Hot Work permit.
Figure 2: EX external components
(1) Display retaining screws
(2) Lid locking set screw
(3) Screw down protective cover
(4) Inlet
(5) Cable glands
(6) Exhaust
