10
INSTALLATION INSTRUCTIONS (Continued)
17. Rotate the trim ring (C) until it hits the stop and cannot be
rotated further. Carefully pull hands away to verify the trim
ring (C) and glass diffuser (D) are securely attached to the
fan housing (A).
Turn on the power source. Test the unit.
17
D
A
C
CARE AND CLEANING
CAUTION: Before attempting to clean the xture, disconnect the power to the xture by turning the breaker off or
removing the fuse from the fuse box.
See safety information before proceeding. Routine maintenance should be done at least once a year.
• Wash glass diffuser with mild soap and water. Dry with a cloth.
• Remove excess dirt and dust from the fan housing with a vacuum cleaner.
• Do not use solvents, thinner or harsh chemicals for cleaning the fan.
• Do not allow water to enter the motor.
• Do not immerse metal parts in water.
• Do not immerse resin parts in water more than 140°F.
WARNING: RISK OF ELECTRIC SHOCK! Ensure
the electricity to the wires you are working on is shut
off. Either remove the fuse or turn off the circuit
breaker before cleaning.
1. Carefully rotate the trim ring (C) and detach it from the
grille with LED light (B).
Wash glass diffuser with mild soap and water. Dry with
a cloth.
1
D
A
C
To Next Page
