EXISTING CONSTRUCTION ASSEMBLY INSTRUCTIONS
7. Plug back in the power unit (7.1). Replace motor
assembly (7.2) using the three screws (7.3)
removed in step 1.
8. Pinch mounting springs (8.1) on grille (8.2) and
insert into narrow rectangular slots (8.3) inside the
fan (A). Push grille (8.2) up toward ceiling.
Turn on electricity at breaker box after nishing
installation.
7
8
7.1
7.2
7.3
8.3
A
8.1
8.1
8.1
