UTILITY ROCKET V1.0

To Next Page

To Previous Page

Rocket Access Point

Note: The following picture is the side view of the Rocket inside the RAP. The Ethernet, Console, and 802.11 5GHz

(A&B) ports are diificult to see while housed inside the RAP’s shell.

From top to bottom: Console port, RAP's Ethernet ports, top and bottoms WiFi ports on the inside of the RAP’s

enclosure.

802.11 5GHz-A

Console Port

Ethernet Ports

Rubber duck 2.4 GHz

802.11 5GHz-B

UTILITY ROCKET V1.0 - Page 8
