SCUBAPRO MK 25/MK 20 First Stages
2003 SCUBAPRO
Important note
: The following information is not designed to be a complete training guide for servicing the listed SCUBAPRO regulators. All SCUBAPRO
technicians are required to attend an annual service training program to insure safe handling and servicing of SCUBAPRO products. All SCUBAPRO technicians
must be employed by an authorized SCUBAPRO facility.
7
Monoject
7/32”
Following cleaning, inspect and
lubricate o’rings and washer as shown.
Reassemble the swivel retainer to the
regulator cap using a 7/32” hex and
torque wrench. Apply 70 in-lbs/8 N-m.
Monoject
Insert the stem o’ring assembly using
the stem o’ring insertion tool. The
o’ring should be lubricated to dynamic
specifications.
Note that the washer with the ledge
should be placed as shown during
reassembly.
Push the assembly into the regulator
body.
To Next Page
