V-TEK DF4-WS - Specification

-
11
-
Power Supply: DC20 ~28 V
Power Consumption : standby 9mA,working 150mA
Working Temperature : -15ºC ~ +55ºC ;
Wiring: 2 wires, non-polarity
Monitor screen: 4.3 Inch digital color LCD
Operation Dimension:
DF4-W, DF4-B:145*145*15.5mm(not include the metal support)
DF4-WS, DF4-BS:138*138*13.8mm(not include the metal support)
Specification
DF4-W DF4-B
DF4-WS DF4-BS
145mm
17.9mm
15.5mm
145mm
138mm
138mm
16.2mm
13.8mm
