V2 ATRIS-700 - Fuse Replacement

ENGLISH
- 31 -
L1L2L3L4L5L6L7L8L9
L10L11
+
B-PACK
ECO-LOGIC
-
LAMP 24Vdc - 3W
+Vdc (Functional Test)
COM COM PHOTO STOP/EDGE START ANT
G1 G2


OK
+Vdc
ACCESSORIES
*
RECEIVER
OVERLOAD
FUSE
8.2 - FUSE
REPLACEMENT
1. Disconnect the motor from
power supply.
2. Loosen the screws on the back
of the motor using an Allen
wrench size 4
3. Remove the cover
4. Replace the fuse with one of
equal value
