DESCRIPTION OF THE CONTROL UNIT
The EASY-BASIC analog control unit is an innovative V2 product
that guarantees safety and reliability for the automation of roller
shutters.
• Adjustment and programming by trimmer and dip-switch
• 230V power supply for 1 single-phase motor
• Built-in radio receiver (433,92 MHz)
• Operation with Personal Pass or Royal series transmitters
• Possibility of storing up to 30 different codes (Personal Pass)
• Start, stop / safety edge inputs
• 1 input for photocells
• STOP input, can also be used to control a resistive edge
(J1 jumper NOT inserted)
• Start and courtesy light from transmitter
• 230V output for flashing light or courtesy light
• Monitoring of input status shown by LEDs
TECHNICAL SPECIFICATIONS
230V models 120V models
Power supply 230 V / 50 Hz 120V / 60Hz
Max motor load 1100 W 600 W
Max accessories load
24 Vac
3 W
Working temperature -20 ÷ +60 °C
Protection fuse F1 = 5A delayed
F2 = 160 mA delayed
Dimensions 170 x 185 x 70 mm
Weight 800 g
Protection IP55
ELECTRIC CONNECTIONS
H1 Antenna
H2 Antenna shield
H3 START. N.O. contact
H4 STOP. N.C. contact
(STOP button - J1 inserted)
EDGE
(Resistive safety edge - J1 NOT inserted)
The intervention of the safety edge disables automatic
closing.
H5 COMMON (-)
H6 PHOTOCELL. N.C. contact
H7-H8 24 Vac power output for photocells and
other accessories
E1 - E2
Flashing light 230Vac / 120Vac
Courtesy light 230Vac / 120Vac
E3 Motor open
E4 Motor common
E5 Motor close
N 230Vac / 120Vac power supply - neutral
L 230Vac / 120Vac power supply - phase
