PORTUGUÊS
- 27 -
PROG
F2
F1
WORK
Rx
PAUSE
H1 H2 H3 H4 H5 H6 H7 H8 E1 E2 E3 E4 E5 N L
START STOP PHOTO
J1
1 2 3 4 5 6
START
STOP / EDGE
COM
24 VAC-3W
COM
LAMP
OPEN
COM
CLOSE
NEUTRAL
PHASE
Max.40W
ANT
m ATENÇÃO: As entradas normalmente fechadas STOP/
EDGE (H4) e PHOTO (H6) se não forem utilizadas, devem ser
ligadas em ponte com o COMUM (H5).
