ENGLISH
47
Pd8 FUNCTION TABLE
DISPLAY DATA DESCRIPTION DEFAULT
MEMO
DATA
S
t.rt
O
peration modes
S
tAn
StAn - Start inputs from terminal board are disabled
no - Standard operation
AP.CH - Separated opening and closing commands
PrES - Manned operation
oroL - Timer operation
FrEn 0 ÷ 10 Brake function 0
StoP STOP input no
no - STOP input not available
invE
- STOP command stops the gate: START command starts moving in the opposite
direction
ProS
- STOP command stops the gate: pressing the START command gate continues the
motion
Fot 1 PHOTO 1 input no
APCh - Input is available for the connection of the photocell
no - Not available
Fot 2 PHOTO 2 input CFCh
CFCh - Photocell is active in closing and also when the gate is still
no - Not available
Ch - Photocell is active during the closing
tESt Test of safety devices no
no - Function not active
Foto - Test enabled only for photocells
CoSt - Test enabled only for safety edges
Ft.Co - Test enabled either for photocells or for safety edges
CoS1 no/Si Border 1 input (fixed border) no
CoS2 no/Si Border 2 input (mobile border) no
C.WE no/Si Enabling WIRELESS edges no
FC.En no/Si End of stroke inputs Si
ASM 0.5” ÷ t.AP Anti-skid function 1.0”
no - Function disabled
SEnS 0 ÷ 10 Obstacle sensor level 0
Cont Counter viewing tot
tot. - Total number of completed cycles (views in thousands or in units)
Man - Number of cycles before the next request for service (such a number has been
rounded off to hundreds and it can be set up on 1000-step; in case it is set up
on 0, the request will be disabled and no will be viewed)
APPr Automatic learning of the operation time no
no - Function disabled
Go - Start up of the automatic learning procedure
FinE End of programming no
no - It does not exit from the program menu
Si - It exits from the program menu by storing the setup parameters
