1.1 - PRELIMINARY CHECKS AND IDENTIFICATION OF THE TYPE TO BE USED
Theautomationdeviceshouldnotbeuseduntilinstallation,asspeciedin“Testingandstart-up”,hasbeenperformed.
Itshouldberememberedthatthedevicedoesnotcompensatefordefectscausedbyimproperinstallation,orpoormaintenance,thus,prior
toproceedingwithinstallation,ensurethatthestructureissuitableandmeetscurrentstandardsand,ifnecessary,performanystructural
modicationsaimedattheimplementationofsafetygapsandtheprotectionorsegregationofallcrushing,shearingandtransitzones,and
verifythat:
• Thegatehasnofrictionpoints,eitherduringclosingoropening.
• Thegateiswellbalanced,i.e.thereisnotendencytomovespontaneouslywhenstoppedinanyposition.
• Thepositionidentiedforxingthemotorreducerallowseasyandsafemanualmanoeuvring,compatiblewiththesizeofthemotor
reduceritself.
• Thesupportonwhichtheautomationdevicewillbexedissolidanddurable.
• Themainspowersupplytowhichtheautomationdeviceisconnectedhasadedicatedsafetyearthingsystemanddifferentialbreaker
withtrippingcurrentlessthanorequalto30mA(thebreakergapdistanceshouldbegreaterthanorequalto3mm).
Warning: The minimum safety level depends on the type of use; please refer to the following outline:
CLOSURE USE TYPE
TYPE OF ACTIVATION
COMMANDS
GROUP 1
Informedpeople
(useinprivatearea)
GROUP 2
Informedpeople
(useinpublicarea)
GROUP 3
Informedpeople
(unlimiteduse)
Man-presentcommand A B Notpossible
Remotecontrolandclosurein
view(e.g.infrared)
CorE CorE CandDorE
Remotecontrolandclosurenot
inview(e.g.radio)
CorE CandDorE CandDorE
Automaticcontrol
(e.g.timedclosurecontrol)
CandDorE CandDorE CandDorE
GROUP 1 - Onlyalimitednumberofpeopleareauthorisedforuse,andclosureisnotinapublicarea.Examplesofthistypearegatesinside
businesspremises,wherethesoleusersareemployees,orapartofthemwhohavebeensuitablyinformed.
GROUP 2 -Onlyalimitednumberofpeopleareauthorisedforuse,butinthiscase,closureisinapublicarea.Anexampleofthismaybea
companygatethataccessesontoapublicstreet,andwhichisonlyusedbyemployees.
GROUP 3 -Anyonecanusetheautomatedclosure,whichisthuslocatedonpublicland.Forexampletheaccessgatetoasupermarketor
anofce,orahospital.
PROTECTION A -Closureisactivatedbymeansofacontrolbuttonwiththepersonpresent,i.e.withmaintainedaction.
PROTECTION B -Withthepersonpresent,closureisactivatedbyacommandcontrolledbymeansofakey-switchorthelike,inorderto
preventusebyunauthorisedpersons.
PROTECTION C -Restrictstheforceoftheleafofthedoororgate.I.e.,inthecaseofthegatestrikinganobstacle,theimpactforcemust
fallwithinacurveestablishedbytheregulations.
PROTECTION D -Devices,suchasphotocells,capableofdetectingthepresenceofpeopleorobstacles.Theymaybeactiveonjustoneside
oronbothsidesofthedoororgate.
PROTECTION E -Sensitivedevices,suchasfootboardsorimmaterialbarriers,capableofdetectingthepresenceofaperson,andinstalledin
suchawaythatthelattercannotbestruckinanywaybyamovingleaforpanel.Thesedevicesshouldbeactivewithintheentire“danger
zone”ofthegate.TheMachineryDirectivedenes“DangerZone”asanyzonesurroundingand/ornearmachinerywherethepresenceof
anexposedpersonconstitutesarisktothehealthandsafetyofthatperson.
The risk analysis should take into consideration all danger zones for the automation device, which should be appropriately
protected and marked.
In a clearly visible area, apply a sign with information identifying the motorised door or gate.
The installer should provide the user with all the information relating to automatic operation, emergency opening and
maintenance of the motorised door or gate.
