Vacon 100 X Installation Manual

1
vacon • 2 VACON® 100 X - Heater (arctic option)
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
1.3.1 Fuses
The recommended fuse types for the heater supply voltage are shown in the table below.
1.4 Mounting instructions: MM4 Example
Figure 1. Heater option for MM4.
X1
Feedback relay output
Switching capacity:
24VDC / 3A
250VAC /3A
Table 3. Fuses ratings.
Fuses for heater supply voltage input - 230VAC
gG/gL (IEC 60269-1)
500V
class T ( UL& CSA)
600V
class J ( UL& CSA)
600V
1A 1A 1A
Table 2. Technical information on input and relay terminals.
Heater connections
Terminal Signal Technical information
