Vacon 100 X User Manual

1
vacon • 2 Vacon 100 X - Heater(arctic option)
1.3.1 Fuses
The recommended fuse types for the heater supply voltage are shown in the table below.
1.4 Mounting instructions: MM4 Example
Figure 1. Heater option for MM4.
Figure 2. Heating element and terminals.
Fuses for heater supply voltage input - 230VAC
gG/gL (IEC 60269-1)
500V
class T ( UL& CSA)
600V
class J ( UL& CSA)
600V
1A 1A 1A
Table 3. Fuses ratings.
