Brake Chopper Application – Parameter lists vacon • 11
24-hour support +358 (0)40 8371 150 • Email: vacon@vacon.com
3.7 Protections (Menu G2 Æ G2.6)
Code Parameter Default Min Max Unit ID Note
P2.6.1 PT100 Numbers 0 0 3 739
Number of PT100
inputs in use at OPT-
B8 option board.
Visible only when the
option board has
been installed
P2.6.2 PT100 Alarm Lim 110 -30 200 °C 1347
Select the
temperature for PT100
sensor above which
PT100 alarm is
generated in the drive.
P2.6.3 PT100 Fault Lim 120
PT100
Alarm
limit
(P2.6.2)
300 °C 1348
Select the
temperature for PT100
sensor above which
PT100 fault is
generated in the drive
P2.6.4 Thermistor 1 0 2 1351
Response to
thermistor
overtemperature.
0=No Action,
1=Warning,
2=Fault
P2.6.5 External Fault 2 0 2 701
Response to External
fault.
0=No action,
1=Warning,
2=Fault
Table 3-9. Protections G2.6
3.8 Keypad control (Control keypad: Menu M3)
Code Parameter Default Min Max Unit ID Description
P3.1 Control place 0 0 1 125
0=I/O terminal (default)
1=Fieldbus
Table 3-10. Keypad control parameters M3
3.9 System menu (Control keypad: Menu M6)
For parameters and functions related to the general use of the frequency converter, such as
application and language selection, customised parameter sets or information about the hardware
and software, see Chapter 7.3.6 in the Vacon NX User's Manual.
3.10 Expander boards (Control keypad: Menu M7)
The M7 menu shows the expander and option boards attached to the control board and board-
related information. For more information, see Chapter 7.3.7 in the Vacon NX User's Manual.
