Description of parameters vacon 15
24-hour support +358 (0)40 8371 150 • Email: vacon@vacon.com
4.3 Output signals
4.3.1 Digital output signals
2.3.1.1 DO1 (ID1216)
Select the signal for controlling the DO1.
0 = Not used
1 = Ready
2 = Running
3 = Fault
4 = No Fault
5 = Warning
6 = Braking active (BCU is braking)
2.3.1.2 DO2 (ID1217)
Select the signal for controlling the relay output 1 (RO1) of OPT-A2 option board.
See parameter P2.3.1.1 for the list of values.
2.3.1.3 DO3 (ID1218)
Select the signal for controlling the relay output 2 (RO2) of OPT-A2 option board.
See parameter P2.3.1.1 for the list of values.
2.3.1.4-
2.3.1.13 DO4 – DO13 (ID1385 – ID1429)
These parameters are only visible when there are additional option boards with digital
outputs installed in the BCU. If for example the option board OPT-B5 has been installed
the parameters for outputs DO4-DO6 become visible.
See parameter P2.3.1.1 for the list of values.
