8 • vacon Brake Chopper Application – Parameter lists
Tel.+358 (0)201 2121 • Fax +358 (0)201 212 205
3.2 Basic parameters (Control keypad: Menu G2 Æ G2.1)
Code Parameter Default Min Max Unit ID Note
P2.1.1
BrkChopper
Level
648
BrakeChopperLev
elMin
BrakeChopperLev
elMax
V 1267
Brake chopper operation
level in volts
P2.1.2 ID Run 0 0 1 631
Manual identification for
brake resistor connection.
Table 3-2. Basic parameters G2.1
3.3 Input signals (Control keypad: Menu G2 Æ G2.2)
3.3.1 Digital inputs (G2.2.1)
Code Parameter Default Min Max Unit ID Note
P2.2.1.1 Fault Reset 3 0 6 1208
Input Selection for Fault
Resetting.
0 = Not used
1 = DIN1
2 = DIN2
3 = DIN3
4 = DIN4
5 = DIN5
6 = DIN6
P2.2.1.2 External Fault 0 0 6 1214
Digital input selection for
external fault signal
connection.
As par. P2.2.1.1
P2.2.1.3 Run Enable 6 0 6 1212
Input selection for Run
Enable Ctrl. 0 = Run
Enabled internally
As par. P2.2.1.1
P2.2.1.4 KLIXON 0 0 6 1209
Input Selection for KLIXON
type Temperature Sensor.
As par. P2.2.1.1
Table 3-3. Digital input parameters G2.2.1
3.3.2 Analog inputs (G2.2.2)
Code Parameter Default Min Max Unit ID Note
P2.2.2.1
PT100 Analog Input
selection
0 0 2 1221
Select the Analog input for
connecting PT100 Sensor.
0=Not Used,
1=AI1,
2=AI2
P2.2.2.2 PT100 In Series 0 0 2 1222
Number of PT100 elements in
series.
0=1*PT100,
1=2*PT100,
2=3*PT100.
Table 3-4. Analog input parameters G2.2.2
