Appendix
0020181421_04 ecoCOMPACT Installation and maintenance instructions 43
Appendix
A Pipe lengths in the B23P installation
Applicability: Germany
Note
The maximum pipe length (straight pipe only) corresponds to the maximum permitted flue gas pipe length without
any elbows. If elbows are used, the maximum pipe length must be reduced in accordance with the dynamic flow
characteristics of the elbows. Elbows must not be connected directly after one another as this method dramatically
increases pressure losses.
VSC 146/4-5 VSC 206/4-5 VSC 266/4-5
Length in m, diameter ≥ 80 mm 40 32 32
