Appendix
0020181421_04 ecoCOMPACT Installation and maintenance instructions 57
VCC_206-4-5_150 VCC_266-4-5_150
Gas supply pressure (G25)
2 kPa 2 kPa
Gas flow at P max. – hot water (G20)
2.59 m³/h 3.24 m³/h
Gas flow at P max. – hot water (G25)
3.01 m³/h 3.76 m³/h
CE number (PIN)
1312CO5870 1312CO5871
Smoke mass flow in heating mode at P min.
1.8 g/s 2.5 g/s
Smoke mass flow in heating mode at P max.
9.2 g/s 11.5 g/s
Smoke mass flow in hot water handling mode at P max.
11.0 g/s 13.8 g/s
Released system types Austria
C13, C33, C43, C53,
C83, C93, B23P,
B33P, B53P
C13, C33, C43, C53,
C83, C93, B23P,
B33P, B53P
Released system types Germany
C13x, C33x, C43x,
C53x, C83x, C93x,
B23P, B33P, B53P
C13x, C33x, C43x,
C53x, C83x, C93x,
B23P, B33P, B53P
Nominal efficiency at 80/60 °C
98 % 98 %
Nominal efficiency at 60/40 °C
101.9 % 103 %
Nominal efficiency at 50/30 °C
105.4 % 106.5 %
Efficiency in partial load operation (30%) at 40/30 °C
108 % 108 %
NOx class
5 5
Boiler dimension, width
599 mm 599 mm
Boiler dimension, depth
693 mm 693 mm
Boiler dimension, height
1,640 mm 1,640 mm
Net weight
140 kg 142 kg
Weight when filled with water
286 kg 288 kg
Technical data – Electrics
VCC_206-4-5_150 VCC_266-4-5_150
Electric connection
230 V / 50 Hz 230 V / 50 Hz
Built-in fuse (slow-blow)
T4A/250 T4A/250
Max. electrical power con-
sumption
105 W 105 W
Standby electrical power
consumption
2.1 W 2.1 W
Level of protection
IP X4 D IP X4 D
J Technical data
Applicability: Belgium
Technical data – Heating
VCC_206-4-5_150 VCC_266-4-5_150 VCC_306-4-5_150
Maximum heating flow
temperature
80 ℃ 80 ℃ 80 ℃
Max. flow temperature ad-
justment range (default
setting: 75 °C)
30 … 80 ℃ 30 … 80 ℃ 30 … 80 ℃
Maximum permissible
pressure
0.3 MPa 0.3 MPa 0.3 MPa
Nominal water flow
(ΔT = 20 K)
861 l/h 1,077 l/h 1,292 l/h
Nominal water flow
(ΔT = 30 K)
574 l/h 718 l/h 861 l/h
