Appendix
46 Installation and maintenance instructions ecoCOMPACT 0020181421_04
Code Parameter Values or explanations
Default
setting
User-spe-
cific setting
D.002 Max. burner anti-cycling time heating
at 20 °C flow temperature
2 … 60 min 20 min
D.003 Parameter not in use for this product Not ad-
justable
D.004 Cylinder domestic hot water temper-
ature
In °C Not ad-
justable
D.005 Heating flow temperature, target
value (or return target value)
In °C, max. of the value set in D.071, limited by an eBUS
controller if connected
Not ad-
justable
D.007 Domestic hot water temperature
target value
35 … 65 ℃ Not ad-
justable
D.009 Heating flow temperature, target
value from external eBUS control
In °C Not ad-
justable
D.010 Status of internal heating pump On, Off Not ad-
justable
D.011 Status of external heating pump On, Off Not ad-
justable
D.012 Status of the cylinder charging pump On, Off Not ad-
justable
D.013 Status of the domestic hot water
circulation pump
On, Off Not ad-
justable
D.014 Target pump speed (high-efficiency
pump)
Target value of internal high-efficiency pump in %. Pos-
sible settings:
0 = Auto
1 = 53
2 = 60
3 = 70
4 = 85
5 = 100
6 = Auto (DP limit) proKlima
7 = Fixed (DP limit) KfW
8 = Auto (pump boost)
0 = Auto
D.015 Actual pump speed (high-efficiency
pump)
Actual value for internal high-efficiency pump in % Not ad-
justable
D.016 24 V DC room thermostat
open/closed
Heating mode off/on Not ad-
justable
D.017 Heating flow/return temperature
control changeover
Control type:
0 = Flow, 1 = Return
0 = Flow
D.018 Pump mode setting 1 = Comfort (continuously operating pump)
3 = Eco (intermittently operating pump)
3 = Eco
D.020 Max. set value for target cylinder
value
Adjustment range: 35-65 °C 65 °C
D.022 Domestic hot water demand On, Off Not ad-
justable
D.023 Summer/winter mode (heating off/on) Heating on, heating off (summer mode) Not ad-
justable
D.025 Domestic hot water generation en-
abled by eBUS control
On, Off Not ad-
justable
D.026 Additional relay actuation 1 = Circulation pump
2 = External pump
3 = Cylinder charging pump (not activated)
4 = Flue non-return flap
5 = External solenoid valve
6 = External fault message
7 = Solar pump (not active)
8 = eBUS remote control (not active)
9 = Anti-legionella pump (not activated)
10 = Solar valve (not active)
1 = Circula-
tion pump
