10 Installation and maintenance instructions ecoFIT pure 0020230533_06

VU 306/6-3 (H-GB)

Electrical connection

230 V / 50 Hz

Built-in fuse (slow-blow)

T2/2A, 250V

Max. electrical power consump-

tion

104 W

Standby electrical power con-

sumption

2 W

IP rating

IPX4D
