0020230533_06 ecoFIT pure Installation and maintenance instructions 7
3 Technical data
Technical data – General
VU 126/6-3 (H-GB) VU 156/6-3 (H-GB) VU 186/6-3 (H-GB) VU 256/6-3 (H-GB)
Gas category
I
2H
I
2H
I
2H
I
2H
Diameter of the gas pipe
1/2 inch 1/2 inch 1/2 inch 1/2 inch
Diameter of the heating connec-
tions
3/4 inch 3/4 inch 3/4 inch 3/4 inch
Expansion relief valve connection
pipe (min.)
15 mm 15 mm 15 mm 15 mm
Condensate discharge pipe (min.)
21.5 mm 21.5 mm 21.5 mm 21.5 mm
G20 gas supply pressure
2.0 kPa
(20.0 mbar)
2.0 kPa
(20.0 mbar)
2.0 kPa
(20.0 mbar)
2.0 kPa
(20.0 mbar)
Gas flow at P max. – hot water
(G20)
1.6 m³/h 1.9 m³/h 2.7 m³/h 3.2 m³/h
Gas flow at P max. – heating mode
(G20)
1.3 m³/h 1.6 m³/h 1.9 m³/h 2.7 m³/h
Gas flow at P min. (G20)
0.476 m³/h 0.480 m³/h 0.533 m³/h 0.648 m³/h
CE number (PIN)
CE-0063CP3646 CE-0063CP3646 CE-0063CP3646 CE-0063CP3646
SAP 2009/2012 annual efficiency
(%)
89.8 89.8 89.7 89.7
Flue gas mass rate in heating
mode at P min.
2.06 g/s 2.08 g/s 2.31 g/s 2.81 g/s
Flue gas mass rate in heating
mode at P max.
5.5 g/s 6.9 g/s 8.3 g/s 11.5 g/s
Flue gas mass rate in hot water
handling mode at P max.
6.9 g/s 8.3 g/s 11.6 g/s 13.8 g/s
Flue gas temperature (80 °C/60 °C)
at P max.
55 ℃ 55 ℃ 60 ℃ 77 ℃
Flue gas temperature (80 °C/60 °C)
at P min.
55 ℃ 55 ℃ 55 ℃ 55 ℃
Flue gas temperature (50 °C/30 °C)
at P max.
43 ℃ 48 ℃ 51 ℃ 62 ℃
Flue gas temperature (50 °C/30 °C)
at P min.
32 ℃ 32 ℃ 34 ℃ 35 ℃
Flue gas temperature in hot water
handling mode
71 ℃ 71 ℃ 69 ℃ 68 ℃
Flue gas temperature when over-
heating
105 ℃ 105 ℃ 105 ℃ 95 ℃
Released system types
C13, C33, C43, C53 C13, C33, C43, C53 C13, C33, C43, C53 C13, C33, C43, C53
Nominal efficiency at 80/60 °C
99.1 % 98.9 % 98.8 % 98.8 %
Nominal efficiency at 50/30 °C
104.0 % 104.0 % 104.0 % 104.0 %
Nominal efficiency at 40/30 °C
106.0 % 106.0 % 106.0 % 106.0 %
Nominal efficiency in partial load
operation (30%) at 40/30 °C
109.9 % 109.9 % 109.8 % 109.8 %
NOx class
5 5 5 5
Product dimensions, width
390 mm 390 mm 390 mm 390 mm
Product dimensions, depth
295 mm 295 mm 295 mm 295 mm
Product dimensions, height
702 mm 702 mm 702 mm 702 mm
Net weight
31 kg 31 kg 31 kg 32 kg
Weight when filled with water
35 kg 35 kg 35 kg 36 kg
VU 306/6-3 (H-GB)
Gas category
I
2H
Diameter of the gas pipe
1/2 inch
Diameter of the heating connec-
tions
3/4 inch
Expansion relief valve connection
pipe (min.)
15 mm

Vaillant ecoFIT pure Series Specifications

General

Mounting	Wall-mounted
Efficiency Rating	A
Fuel Type	Natural Gas
Warranty	2 years
Model	ecoFIT pure
Dimensions	700mm x 390mm x 295mm
Efficiency	94%
