3.7 Flue termination
The following details refer to both flue systems.
a.
The terminal must be located where the combustible
substances can escape freely at all times.
b. A plume of water vapour will sometimes be visible
from the flue terminal. Positions where this could be
a nuisance should be avoided.
c. If the terminal is fitted less than 2 m above a balcony,
above ground or above a flat roof to which people
have access then a suitable terminal guard must be
provided and fitted (made by Tower Flue
Components, Tonbridge, TN9 1TB, Model K3, plastic
coated).
A
BCD
A
G
H, I
F
J
B
F
M
L
L
K
K
G
G
F
F
E
A
A
Fig. 3.8 Flue termination
i
Vertical flues must not terminate within
600 mm of an openable window, air vent or
any other ventilation opening.
b
Caution!
Possible material damage caused by lubri-
cating the seals!
Mineral oil-based lubricants may damage the
seals. The seals should therefore not be lubri-
cated.
> Only use water or commercially available
soft soap, if necessary, to assist with instal-
lation.
