- 12 -
• Donotplaceneartostaleairextractionfans.
• Allowroomforelectricitycables(highandlowvoltage).
• Explaintheserequirementstotheapplianceuser.
 
>100mm
• Makeallowanceforacondensatedischargecircuit.
 
• Pleaseensurethatallcorrectpermissionshavebeenobtained
fromthelocalplanningoce,priortositingtheappliance.

i
All the drawings dimensions are shown in mm.
 
 
 
• Beforechoosingasitefortheappliance,carefullyreadthe
safetywarningsandinstallationmanual.
• Ensurethereissucientspaceavailablefortheappliance,
takingcarethatminimumclearancesareadheredtoensure
thattheconnectionstothewater,gasanduecanbe
accessedandinspected(seechapterClearances).
• Observecurrentregulations.
• Installtheapplianceoutside.
• Donotinstalltheappliance:
- nearaheatsource,
- nearammablematerials,
- neartheventilationpointsofadjacentbuildings
- beneathdeciduoustrees.
• Takeintoaccountthefollowingwheninstallingtheheatpump:
- prevailingwinds,
- thenoisegeneratedbythefanandthecompressor
- thevisualimpactonthesurroundingneighbourhood.
• Avoidareasexposedtostrongwindsdirectedagainstthe
appliance’sairoutlet.
• Settheapplianceononeofthefollowingsupports:
- concreteslabs,
- cranebeam,
- concreteblocks.
• Donotinstallthefanfacingthenearbywindows.Ifnecessary,
installanoisebarrier.
• Toavoidtransmissionofvibrationstothesurrounding
buildings:
- usehosesforwaterconnections,
- installanti-vibrationpads.
• Ensurethattheapplianceisprotectedfromwaterandfrom
snow.
• Donotexposetheheatpumptocorrosiveordusty
atmospheres(neartodirtroads,forexample).
INSTALLATION

Vaillant geoTHERM SERIES Specifications

General

Type	Air-to-Water Heat Pump
Cooling Capacity	3.0 - 14.0 kW
Operating Temperature Range (Cooling)	10 - 46 °C
Operating Temperature Range (Heating)	-20°C to 35°C
Coefficient of Performance (COP)	4.0 - 4.8 (Depending on Model)
