Installer_manual_OEM_Vaillant_PROTO_3_GB-06/11-Vaillant
- 3 -
 
 
Theinstructionsareanintegralpartoftheapplianceandmustbe
handedtotheuseroncompletionoftheinstallationinorderto
complywiththecurrentregulation.
• Carefullyreadthemanual,tounderstandalltheinformation
toenablesafeinstallation,useandservicing.Noliabilitycan
beacceptedintheeventofdamagefornotcomplyingwiththe
guidanceinthisinstructionmanual.
Theseinstructionsconsistof,Installation,Servicing,FaultFinding
andReplacementofParts.Theinstructionsareanintegralpartof
theapplianceandmustbehandedtotheuseroncompletionof
theinstallation.
 
- 1Instructionsforuser
- Instructionsforothersystemcomponents
 
a
DANGER: Risk of injuries.
e
DANGER: Risk of electric shock.
b
ATTENTION: Risk of damage to the appliance or to its
surroundings.
i
IMPORTANT: Important information.
 
 
- Thisapplianceisdesignedforuseinheatingwithanexternal
temperatureofbetween-20°Cand30°C.Outsidethisrange,
theheatpumpstops.
- Asetofsecuritydevicesbasedonmeasuringthetemperature
withinthecircuitsandthecurrentinthecompressorprotects
itagainstexcesspressureintherefrigeratinguid.
- Aowdetectorprotectstheapplianceasawhole.
- Topreventstagnationoftherefrigerantuidwhenthe
compressorisstopped,asafetydeviceisactivatedwhenthe
outsidetemperaturelowers.Thecompressoristhenheatedby
alowelectricalcurrentthroughthemotorwindings,
- Atemperaturesensoronexitfromthecompressorlimitsthe
functioningoftheheatpumpwhenthetemperaturemeasured
bythissensorisgreaterthan100°C.From117°C,theheat
pumpstops.
- Atemperaturesensoronthetubularheatexchangeranda
tachometeronthefanchecksthatthefanisworking.
- Awaterowsensorensuresthesecurityofthewater
circulation.Iftheowistoolow(<420l/h),theappliance
stopsandre-startswhentheowcomeswithinthenormal
functioningrange(>500l/h).
 
Thedatalabelcertiesthecountrywheretheapplianceis
intendedtobeinstalled.
Datalabellocation:
1

 
INTRODUCTION
