• Makesurethatthematerialsusedforperformingthe
installationarecompatiblewiththoseoftheappliance.
• Determinetheplaceofassembly.Seethechapter"Location".
3
3
1
1
4
2

 
 
 
 
• Separatethecommandunitfromthewallsupport(3).
• Passtheelectricalconnectioncablesthroughtheholeonthe
leftoftheconnectorandconnectthemontoterminal(4).See
thechapter"Installationexamples".
• Positionthesupport(3)onawall.
• Drillholesforthexingscrewsinaccordancewiththe2xing
holesonthewallsupport(3).
• Inserttherawlplugs(2)intheholes.
• Fixthesupport(3)withthexingscrews(supplied).
2
1

 
 
• Assemblethecommandunit(1)onthewallsupport(2).
 
 
1
3
4
2
2.1
2.2
2.4
2.3
2.2
2.4
2.3
3.1
3.2
3.3

  
  
   
  


INSTALLATION

Vaillant geoTHERM SERIES Specifications

General

Type	Air-to-Water Heat Pump
Cooling Capacity	3.0 - 14.0 kW
Operating Temperature Range (Cooling)	10 - 46 °C
Operating Temperature Range (Heating)	-20°C to 35°C
Coefficient of Performance (COP)	4.0 - 4.8 (Depending on Model)
