18
OPERATION
Status display
(For maintenance and service work
performed by your installer or service
agent)
The status displays are activated by
pressing the „i“ button (1). The
current status code, e.g. „S.34“ for
the frost protection mode, is shown
on the display (2).
Pressing the „i“ button again will
switch you back to the normal mode.
The „+“ and „-“ buttons will only be
used by your installer or service agent
during service and maintenance
work.
Fig. B.16: Status displays
Table B.1: Status displays (A complete overview of the status codes can be found in the installation instructions).
* Heating operation
** Hot water operation (TURBOmax Plus only)
Euro B/S 081/1
Display Meaning
S.00* No heating required
S.01* Fan running
S.03* Ignition sequence
S.04* Burner ignited
S.05* Fan and water pump over run
S.07* Water pump over run
S.08* Anti cycling mode (after heating operation)
S.10** Hot water demand
S.34* Frost protection mode
S.14** Burner ignited
