33GBInstallation instructions VRT 360f
1
1
3
2
2
4
5
Fig. 9.2 Mounting the receiver
9.3 Mounting the room temperature
thermostat
Check the site of installation before
fitting the unit with regard to possible
radio interference by electrical
equipment or building influences which
may affect the functioning. If the radio
signal route is compromised then an
alternative installation site must be
chosen.
• Pull the room temperature thermostat
(1) off the wall plinth (3).
• Drill two holes (2) of 6 mm diameter
(as shown in fig. 9.3) and put in the
supplied wall plugs.
• Attach the wall plinth to the wall with
the two screws provided.
Installation 9
